 YEAR

2004

LOCATED IN

CURACAO



LENGHT

48'

PRICE

US$ 305,000



Engine/Fuel Type

DIESEL

HULL MATERIAL

FIBERGLASS




Dimensions

  • LOA: 49 ft 0 in
  • Beam: 16 ft 0 in
  • Maximum Draft: 4 ft 4 in
  • Dry Weight: 46000 lbs
  • Engines

  • Total Power: 2050 HP
  • Engine 1:
  • Engine Brand: Caterpillar
  • Engine Model: Twin cat C-18
  • Engine Type: Inboard
  • Engine/Fuel Type: Diesel
  • Location: Center
  • Engine Hours: 1950
  • Drive Type: Direct Drive
  • Engine Power: 1025 HP
  • Engine 2:
  • Engine Brand: Caterpillar
  • Engine Model: Twin cat C-18
  • Engine Type: Inboard
  • Engine/Fuel Type: Diesel
  • Location: Center
  • Engine Hours: 1950
  • Drive Type: Direct Drive
  • Engine Power: 1025 HP
  • Cruising Speed: 28 knots @ 1890 RPM
  • Maximum Speed: 35 knots
  • Tanks

  • Fresh Water Tanks: Fiberglass (800 Gallons)
  • Fuel Tanks: Fiberglass (800 Gallons)
  • Holding Tanks: Fiberglass (100 Gallons)
  • Accommodations

  • Number of double berths: 1
  • Number of cabins: 1
  • Number of heads: 1
  • Seating Capacity: 12
  • Electronics

  • Wind speed and direction
  • Radar Detector
  • Depthsounder
  • TV set - Two
  • Compass
  • GPS - Garmin 7610XSV
  • Autopilot - Simrad APV28
  • DVD player
  • Navigation center
  • Plotter
  • Inside equitment

  • Refrigerator
  • Air compressor
  • Microwave oven
  • Battery charger
  • Deep freezer
  • Washing machine
  • Dishwasher
  • Hot water
  • Electric bilge pump
  • Air conditioning
  • Heating
  • Electric head - Raritan
  • Battery charger
  • Fresh water maker - Village Marine Tec.
  • Sea water pump
  • Electrical equipment

  • Generator
  • Shore power inlet
  • Electrical Circuit: 24V
  • Outside Equipment/Extras

  • Total Liferaft Capacity: 6
  • Electric windlass
  • Covers

  • Cockpit cover
  •


    Additional work

    1. 2012, a 11.5 kw northern lights generator was installed

    2. 2013  entiresteering system overhaul including all seals,pump and piston serviced or replaced.

    3. 2013 new awlgrip paint (royal blue).

    4. 2015 pumps replaced:

      a) Engines and generator raw water pump.

      b) A/C pump.

      c)  Macerator pump(fishbox).

      d) Salt & freash water.

      e) Water maker(low pressure pump).

      f) Rawwater freezer pump (copckit).

    1. 2015 Propellers were taken down for a propscan tune up.

    2. 2016 new electronic package

    3. 2016  engines serviced at 1500hrs by Servmarine/CAT :

    a) 2 new engine displays.

    b) Aftercoolers, Radiators and turbos were taken.

                c) Serviced & Cleaned. coolant and all seals.

    d) Coolant and all seals were replaced .

    e) Replacement of Air Filters, belts, thermostats, all engine and generator hoses and all batteries.

    f) Valves and injectors calibrated/changed/cleaned.

    1.   2018 Haul out for new antifouling,shaft alignment and new zincs.

    2. All seacocks, shafts and rudders were serviced. props were taken down for a tuneup and scan.
